Authentication and Authorization Guide¶

The MCP Gateway Registry provides enterprise-ready authentication and authorization using industry-standard OAuth 2.0 flows with fine-grained access control.

Quick Navigation¶

I want to... - Build an AI agent with authentication → Quick Start - Understand the authentication architecture → Architecture - Set up external service integration → Egress Auth - Configure fine-grained permissions → FGAC - See all configuration options → Reference

Quick Start for AI Agents¶

Get your AI agent authenticated and running in 5 minutes.

Prerequisites¶

• Keycloak service account credentials (provided by your administrator)
• Access to external services you want to integrate (optional)

Step 1: Configure Environment¶

Create credentials-provider/oauth/.env with your credentials:

# Authentication Provider Selection
AUTH_PROVIDER=keycloak

# Keycloak Ingress Authentication (Required for MCP Gateway access)
KEYCLOAK_URL=https://mcpgateway.ddns.net
KEYCLOAK_REALM=mcp-gateway
KEYCLOAK_M2M_CLIENT_ID=agent-your-agent-name-m2m
KEYCLOAK_M2M_CLIENT_SECRET=your_keycloak_m2m_client_secret

# Alternative: Cognito (if AUTH_PROVIDER=cognito)
# AWS_REGION=us-east-1
# INGRESS_OAUTH_USER_POOL_ID=us-east-1_XXXXXXXXX
# INGRESS_OAUTH_CLIENT_ID=your_cognito_client_id
# INGRESS_OAUTH_CLIENT_SECRET=your_cognito_client_secret

# Egress Authentication (Optional - for external services)
EGRESS_OAUTH_CLIENT_ID_1=your_external_provider_client_id
EGRESS_OAUTH_CLIENT_SECRET_1=your_external_provider_client_secret
EGRESS_OAUTH_REDIRECT_URI_1=http://localhost:9999/callback
EGRESS_PROVIDER_NAME_1=atlassian
EGRESS_MCP_SERVER_NAME_1=atlassian

Pro Tip: Use the example files as templates:

# Copy and customize the example configurations
cp credentials-provider/oauth/.env.example credentials-provider/oauth/.env
cp .env.example .env

# Edit with your actual credentials

Step 2: Run OAuth Setup¶

cd credentials-provider
./generate_creds.sh

# Available options:
# ./generate_creds.sh --all              # Run all authentication flows (default)
# ./generate_creds.sh --ingress-only     # Only MCP Gateway authentication
# ./generate_creds.sh --egress-only      # Only external provider authentication
# ./generate_creds.sh --agentcore-only   # Only AgentCore token generation
# ./generate_creds.sh --provider google  # Specify provider for egress auth
# ./generate_creds.sh --verbose          # Enable debug logging

# This will:
# 1. Authenticate with Keycloak (M2M) or Cognito (M2M/2LO)
# 2. Optionally authenticate with external services (3LO)
# 3. Generate AgentCore tokens if configured
# 4. Generate Keycloak agent tokens if configured
# 5. Generate MCP client configurations
# 6. Add no-auth services to configurations

Step 3: Use Generated Configuration¶

The script generates ready-to-use MCP client configurations:

For VS Code (~/.vscode/mcp.json):

{
  "mcp": {
    "servers": {
      "mcpgw": {
        "url": "https://mcpgateway.ddns.net/mcpgw/mcp",
        "headers": {
          "X-Authorization": "Bearer {your_keycloak_jwt_token}",
          "X-Client-Id": "{agent_client_id}",
          "X-Keycloak-Realm": "mcp-gateway",
          "X-Keycloak-URL": "http://localhost:8080"
        }
      },
      "atlassian": {
        "url": "https://mcpgateway.ddns.net/atlassian/mcp",
        "headers": {
          "Authorization": "Bearer {atlassian_oauth_token}",
          "X-Atlassian-Cloud-Id": "{cloud_id}",
          "X-Authorization": "Bearer {your_keycloak_jwt_token}",
          "X-Client-Id": "{agent_client_id}",
          "X-Keycloak-Realm": "mcp-gateway",
          "X-Keycloak-URL": "http://localhost:8080"
        }
      }
    }
  }
}

For AI Coding Assistants (Create your token configuration using these actual patterns):

{
  "mcpServers": {
    "mcpgw": {
      "type": "streamable-http",
      "url": "https://mcpgateway.ddns.net/mcpgw/mcp",
      "headers": {
        "X-Authorization": "Bearer eyJhbGciOiJSUzI1NiIsInR5cCI6IkpXVCJ9...",
        "X-Client-Id": "agent-ai-coding-assistant-m2m",
        "X-Keycloak-Realm": "mcp-gateway",
        "X-Keycloak-URL": "http://localhost:8080"
      },
      "disabled": false,
      "alwaysAllow": []
    },
    "atlassian": {
      "type": "streamable-http",
      "url": "https://mcpgateway.ddns.net/atlassian/mcp",
      "headers": {
        "Authorization": "Bearer eyJraWQiOiJhdXRoLmF0bGFzc2lhbi5jb20tQUNDRVNTLTk0ZTczYTkwLTUxYWQtNGFjMS1hOWFjLWU4NGUwNDVjNDU3ZCIsImFsZyI6IlJTMjU2In0...",
        "X-Atlassian-Cloud-Id": "923a213e-e930-4359-be44-f4b164d3f269",
        "X-Authorization": "Bearer eyJhbGciOiJSUzI1NiIsInR5cCI6IkpXVCJ9...",
        "X-Client-Id": "agent-ai-coding-assistant-m2m",
        "X-Keycloak-Realm": "mcp-gateway",
        "X-Keycloak-URL": "http://localhost:8080"
      },
      "disabled": false,
      "alwaysAllow": []
    }
  }
}

To Generate Your Own Tokens:

1. Create Keycloak Service Account for your AI agent:

   # Run from the project root
   ./keycloak/setup/setup-agent-service-account.sh --agent-id ai-coding-assistant --group mcp-servers-unrestricted


2. Generate Agent Token:

   # Generate M2M token for your agent
   uv run python credentials-provider/keycloak/generate_tokens.py --agent-id ai-coding-assistant

   # Check generated token file
   cat .oauth-tokens/agent-ai-coding-assistant-m2m-token.json


3. Create MCP Configuration:

   # Run complete credential generation
   ./credentials-provider/generate_creds.sh --keycloak-only

   # Your configuration will be in:
   # - .oauth-tokens/mcp.json (for Claude Code/Roocode)
   # - .oauth-tokens/vscode_mcp.json (for VS Code)


Important: Use your actual generated tokens - the examples above are truncated for security.

Step 4: Test Your Connection¶

# Example: Using the MCP client with authentication
import json
import os
from pathlib import Path
from langchain_mcp_adapters.client import MultiServerMCPClient

# Method 1: Load configuration from ~/.vscode/mcp.json
def load_mcp_config_from_file():
    """Load MCP configuration from VS Code config file."""
    config_path = Path.home() / ".vscode" / "mcp.json"

    if not config_path.exists():
        # Fallback to oauth-tokens directory if VS Code config doesn't exist
        config_path = Path.cwd() / ".oauth-tokens" / "vscode_mcp.json"

    if config_path.exists():
        with open(config_path, 'r') as f:
            config = json.load(f)
            # Extract the servers configuration
            return config.get("mcp", {}).get("servers", {})
    else:
        raise FileNotFoundError(f"MCP configuration not found at {config_path}")

# Method 2: Direct configuration (as shown in agent.py)
def create_mcp_client_direct(auth_token, user_pool_id, client_id, region):
    """Create MCP client with direct configuration."""
    auth_headers = {
        'X-Authorization': f'Bearer {auth_token}',
        'X-User-Pool-Id': user_pool_id,
        'X-Client-Id': client_id,
        'X-Region': region
    }

    return MultiServerMCPClient({
        "mcp_gateway": {
            "url": "https://mcpgateway.ddns.net/mcpgw/mcp",
            "transport": "sse",
            "headers": auth_headers
        }
    })

# Usage Example - Loading from config file
async def connect_with_config_file():
    # Load configuration from file
    servers_config = load_mcp_config_from_file()

    # Initialize MCP client with loaded configuration
    mcp_client = MultiServerMCPClient(servers_config)

    # Discover available tools (filtered by your permissions)
    tools = await mcp_client.get_tools()
    return tools

# Usage Example - Direct configuration (useful for agents)
async def connect_with_params(token, pool_id, client_id, region="us-east-1"):
    # Create client with parameters
    mcp_client = create_mcp_client_direct(token, pool_id, client_id, region)

    # Discover available tools
    tools = await mcp_client.get_tools()
    return tools

That's it! Your agent is now authenticated and can access MCP servers based on your assigned permissions.

Integration with Agent Applications¶

The agents/agent.py file demonstrates how to integrate authentication in a production agent:

# Example from agents/agent.py showing MultiServerMCPClient usage
from langchain_mcp_adapters.client import MultiServerMCPClient

# The agent can read auth parameters from multiple sources:
# 1. Command-line arguments (--client-id, --client-secret, etc.)
# 2. Environment variables (COGNITO_CLIENT_ID, etc.)
# 3. Configuration files (.env.agent, .env.user)
# 4. VS Code MCP config (~/.vscode/mcp.json)

# Current implementation in agent.py:
auth_headers = {
    'X-Authorization': f'Bearer {access_token}',
    'X-User-Pool-Id': args.user_pool_id,
    'X-Client-Id': args.client_id,
    'X-Region': args.region
}

client = MultiServerMCPClient({
    "mcp_registry": {
        "url": server_url,
        "transport": "sse",
        "headers": auth_headers
    }
})

# To enhance agent.py to read from ~/.vscode/mcp.json:
# Add a function to load config from file as a fallback
# when auth parameters are not provided via CLI or env vars

For a complete working example, see agents/agent.py which implements: - Multiple authentication methods (M2M, session cookies, JWT tokens) - Dynamic token generation and refresh - Comprehensive error handling and logging - Integration with LangChain and Anthropic models

Authentication Architecture¶

Overview¶

The MCP Gateway Registry uses a comprehensive three-layer authentication system:

1. Ingress Authentication (2LO): Gateway access using Keycloak or Amazon Cognito
2. Egress Authentication (3LO): External service integration via OAuth providers
3. Fine-Grained Access Control (FGAC): Permission management at method and tool level

Key Concepts¶

• Dual Token System: AI agents carry BOTH ingress and egress tokens
• Token Storage: After authentication, tokens are stored locally and used by AI agents
• Header Passing: Both token sets are passed as headers from AI agent to gateway
• Validation Points:
• Ingress tokens validated by gateway with Keycloak or Cognito
• FGAC enforced at gateway level using group-based permissions
• Egress tokens passed through to MCP servers for their validation

High-Level Authentication Flow¶

sequenceDiagram
    participant User as User/Developer
    participant Agent as AI Agent
    participant Auth as Keycloak/Cognito<br/>(Ingress IdP)
    participant ExtIdP as External IdP<br/>(e.g., Atlassian)
    participant Gateway as MCP Gateway
    participant MCPServer as MCP Server

    Note over User,MCPServer: One-Time Setup

    User->>Cognito: 1. Authenticate (2LO)
    Cognito->>User: Ingress Token

    User->>ExtIdP: 2. Authenticate & Approve (3LO)
    Note right of User: "Allow AI agent to<br/>act on my behalf"
    ExtIdP->>User: Egress Token

    User->>Agent: 3. Configure with both tokens

    Note over Agent,MCPServer: Runtime (Every Request)

    Agent->>Gateway: 4. Request with dual tokens<br/>(Ingress + Egress headers)
    Gateway->>Cognito: 5. Validate ingress auth
    Gateway->>Gateway: 6. Apply FGAC
    Gateway->>MCPServer: 7. Forward with egress token
    MCPServer->>ExtIdP: 8. Validate egress auth
    MCPServer->>Agent: 9. Response (via Gateway)

Complete End-to-End Flow (Detailed)¶

sequenceDiagram
    participant User as User/Developer
    participant Agent as AI Agent
    participant Browser as Browser
    participant Cognito as Amazon Cognito<br/>(Ingress IdP)
    participant ExtIdP as External IdP<br/>(e.g., Atlassian)
    participant Gateway as MCP Gateway
    participant AuthServer as Auth Server<br/>(in Gateway)
    participant MCPServer as MCP Server

    Note over User,MCPServer: PHASE 1: One-Time Setup & Authentication

    rect rgb(240, 248, 255)
        Note over User,Cognito: Step 1: Ingress Authentication (2LO/M2M)
        User->>Cognito: 1. Client Credentials Grant<br/>(client_id + client_secret)
        Cognito->>User: 2. JWT Token with scopes
        User->>User: 3. Store ingress token locally
    end

    rect rgb(255, 248, 220)
        Note over User,ExtIdP: Step 2: Egress Authentication (3LO)
        User->>Browser: 4. Initiate OAuth flow
        Browser->>ExtIdP: 5. Redirect to provider login
        User->>ExtIdP: 6. User authenticates
        User->>ExtIdP: 7. Reviews & approves permissions<br/>"Allow AI agent to act on my behalf"
        ExtIdP->>Browser: 8. Auth code redirect
        Browser->>User: 9. Capture auth code
        User->>ExtIdP: 10. Exchange code for tokens
        ExtIdP->>User: 11. Access & refresh tokens
        User->>User: 12. Store egress tokens locally
    end

    rect rgb(240, 255, 240)
        Note over User: Step 3: Configure AI Agent
        User->>User: 13. Create configuration with:<br/>- Server URLs<br/>- Ingress headers (X-Authorization, etc.)<br/>- Egress headers (Authorization, etc.)
    end

    Note over Agent,MCPServer: PHASE 2: Runtime - AI Agent Uses Tokens

    rect rgb(255, 240, 245)
        Note over Agent,MCPServer: Every MCP Request
        Agent->>Gateway: 14. MCP Request with headers:<br/>X-Authorization: Bearer {ingress_jwt}<br/>Authorization: Bearer {egress_jwt}<br/>X-User-Pool-Id, X-Client-Id, X-Region

        Gateway->>AuthServer: 15. Extract & validate ingress token
        AuthServer->>Cognito: 16. Verify JWT signature & claims
        Cognito->>AuthServer: 17. Token valid + user scopes

        AuthServer->>AuthServer: 18. Apply FGAC rules<br/>(Check tool/method permissions)

        Gateway->>MCPServer: 19. Forward request with egress headers:<br/>Authorization: Bearer {egress_jwt}

        MCPServer->>ExtIdP: 20. Validate egress token
        ExtIdP->>MCPServer: 21. Token valid + permissions

        MCPServer->>MCPServer: 22. Execute requested action<br/>(within approved scope)

        MCPServer->>Gateway: 23. Response
        Gateway->>Agent: 24. Response
        Agent->>User: 25. Display result
    end

Authentication Types Explained¶

Two-Legged OAuth (2LO) - Ingress¶

• Purpose: Authenticate agents/users TO the MCP Gateway
• Provider: Amazon Cognito
• Use Case: M2M authentication for AI agents
• Token Type: JWT with embedded scopes

Three-Legged OAuth (3LO) - Egress¶

• Purpose: Authenticate FROM the Gateway to external services
• Providers: Atlassian, Google, GitHub, others
• Use Case: Access external APIs on behalf of users
• Token Type: Provider-specific OAuth tokens

Token Header Mapping¶

Headers sent from AI Agent to Gateway:¶

{
  "headers": {
    // Ingress Authentication (for Gateway) - Keycloak
    "X-Authorization": "Bearer {keycloak_jwt_token}",
    "X-Client-Id": "{agent_client_id}",
    "X-Keycloak-Realm": "mcp-gateway",
    "X-Keycloak-URL": "http://localhost:8080",

    // OR Ingress Authentication (for Gateway) - Cognito
    "X-Authorization": "Bearer {cognito_jwt_token}",
    "X-User-Pool-Id": "{cognito_user_pool_id}",
    "X-Client-Id": "{cognito_client_id}",
    "X-Region": "{aws_region}",

    // Egress Authentication (for MCP Server) - Example: Atlassian
    "Authorization": "Bearer {atlassian_oauth_token}",
    "X-Atlassian-Cloud-Id": "{atlassian_cloud_id}"
  }
}

Headers forwarded from Gateway to MCP Server:¶

{
  "headers": {
    // Only egress headers are forwarded (provider-specific)
    "Authorization": "Bearer {external_provider_token}",
    "X-Atlassian-Cloud-Id": "{atlassian_cloud_id}"  // For Atlassian
    // OR other provider-specific headers as needed
  }
}

Key Security Layers¶

Layer 1: Ingress Authentication (2LO)¶

• Purpose: Controls who can access the MCP Gateway
• Validation: Gateway validates with Cognito
• Headers: X-Authorization, X-User-Pool-Id, X-Client-Id, X-Region
• Methods: Machine-to-Machine (M2M), User Authentication to Registry UI

Layer 2: Fine-Grained Access Control (FGAC)¶

• Purpose: Controls which tools/methods within MCP servers can be accessed
• Validation: Applied at Gateway level after ingress auth
• Based on: User/agent scopes and permissions

Layer 3: Egress Authentication (3LO)¶

• Purpose: Allows MCP servers to act on user's behalf with external services
• Validation: MCP server validates with its IdP (e.g., Atlassian)
• Headers: Authorization, provider-specific headers

External Service Integration¶

Supported Providers¶

• Atlassian Cloud: Jira, Confluence integration
• Google: Workspace, Gmail, Drive access
• GitHub: Repository and organization access
• Others: See agents/oauth/oauth_providers.yaml for complete list

Setting Up External Provider (Atlassian Example)¶

1. Create Developer App
2. Visit developer.atlassian.com
3. Create OAuth 2.0 (3LO) app

4. Set redirect URI: http://localhost:8080/callback

5. Configure Credentials

   # In credentials-provider/oauth/.env
   EGRESS_OAUTH_CLIENT_ID_1=your_atlassian_client_id
   EGRESS_OAUTH_CLIENT_SECRET_1=your_atlassian_client_secret
   EGRESS_OAUTH_REDIRECT_URI_1=http://localhost:8080/callback
   EGRESS_PROVIDER_NAME_1=atlassian
   EGRESS_MCP_SERVER_NAME_1=atlassian


6. Run Authentication

   cd credentials-provider
   ./generate_creds.sh  # This will handle both ingress and egress auth


Fine-Grained Access Control (FGAC)¶

The FGAC system provides granular permissions for MCP servers, methods, and individual tools.

Key Concepts¶

Scope Types¶

• UI Scopes: Registry management permissions
• mcp-registry-admin: Full administrative access

• mcp-registry-user: Limited user access

• Server Scopes: MCP server access

• mcp-servers-unrestricted/read: Read all servers
• mcp-servers-unrestricted/execute: Execute all tools
• mcp-servers-restricted/read: Limited read access
• mcp-servers-restricted/execute: Limited execute access

Methods vs Tools¶

The system distinguishes between:

• MCP Methods: Protocol operations (initialize, tools/list, tools/call)
• Individual Tools: Specific functions within servers

Access Control Example¶

# User can list tools but only execute specific ones
mcp-servers-restricted/execute:
  - server: fininfo
    methods:
      - tools/list        # Can list all tools
      - tools/call        # Can call tools
    tools:
      - get_stock_aggregates   # But only these specific tools
      - print_stock_data       # Not other tools in the server

Common Scenarios¶

For complete FGAC documentation, see Fine-Grained Access Control.

Implementation Guide¶

Running OAuth Authentication¶

Complete Setup (Ingress + Egress)¶

cd agents/oauth
./oauth_creds.sh                    # Interactive mode
./oauth_creds.sh --provider atlassian --force  # Specific provider

Ingress Only (Gateway Access)¶

./oauth_creds.sh --ingress-only
# Or directly:
python ingress_oauth.py --verbose

Egress Only (External Services)¶

./oauth_creds.sh --egress-only --provider atlassian
# Or directly:
python egress_oauth.py --provider atlassian

Authentication Headers Reference¶

Headers are automatically managed by the OAuth scripts, but here's what gets sent:

For MCP Gateway (Ingress)¶

For External Services (Egress)¶

Configuration Reference¶

📋 For complete configuration documentation, see Configuration Reference

The Configuration Reference provides comprehensive documentation for all configuration files including:

• Environment Variables: .env files with complete parameter documentation
• YAML Configurations: All .yml and .yaml files with field descriptions
• Example Files: .env.example and config.yaml.example templates
• Security Best Practices: Credential management and file permissions
• Troubleshooting: Common configuration issues and solutions

Quick Reference¶

Key Configuration Files¶

OAuth Provider Configuration¶

Providers are configured in credentials-provider/oauth/oauth_providers.yaml:

providers:
  atlassian:
    display_name: "Atlassian Cloud"
    auth_url: "https://auth.atlassian.com/authorize"
    token_url: "https://auth.atlassian.com/oauth/token"
    scopes:
      - "read:jira-work"
      - "write:jira-work"
    requires_cloud_id: true

Scope Configuration¶

Access control is defined in auth_server/scopes.yml:

group_mappings:
  mcp-registry-admin:
    - mcp-registry-admin
    - mcp-servers-unrestricted/read
    - mcp-servers-unrestricted/execute

mcp-servers-restricted/read:
  - server: currenttime
    methods:
      - tools/list
    tools:
      - current_time_by_timezone

Generated Output Files¶

The OAuth scripts generate:

• VS Code Config: ~/.vscode/mcp.json - Primary configuration for VS Code integration
• Local VS Code Config: .oauth-tokens/vscode_mcp.json - Local copy of VS Code config
• Roocode Config: ~/.roocode/mcp_servers.json - Configuration for Roocode
• Local Roocode Config: .oauth-tokens/mcp.json - Local copy of Roocode config
• Token Storage: .oauth-tokens/ingress.json, .oauth-tokens/egress.json - Raw token data

Using Configuration Files in Your Code¶

The generated configuration files can be used directly with MultiServerMCPClient:

# Option 1: Load from VS Code config location
config_path = Path.home() / ".vscode" / "mcp.json"

# Option 2: Load from local oauth-tokens directory
config_path = Path.cwd() / ".oauth-tokens" / "vscode_mcp.json"

# Parse and use the configuration
with open(config_path) as f:
    config = json.load(f)
    servers = config.get("mcp", {}).get("servers", {})
    client = MultiServerMCPClient(servers)

Security Considerations¶

Best Practices¶

1. Token Storage: Tokens stored with 600 permissions in .oauth-tokens/
2. Environment Security: Never commit .env files
3. Scope Management: Follow principle of least privilege
4. Network Security: HTTPS-only, PKCE where supported

Token Lifecycle¶

• Ingress tokens: 1-hour expiry, auto-refresh via client credentials
• Egress tokens: Provider-specific, refresh tokens where available
• Session management: Handled automatically by OAuth scripts
• Automated refresh service: Background service monitors and refreshes all tokens

Token Refresh Service¶

The MCP Gateway includes an Automated Token Refresh Service that provides:

• Continuous monitoring of all OAuth tokens for expiration
• Proactive refresh before tokens expire (configurable 1-hour buffer)
• Automatic MCP config generation for coding assistants
• Service discovery for both OAuth and no-auth services
• Background operation with comprehensive logging

Start the token refresh service:

./start_token_refresher.sh

The service automatically generates MCP configurations for: - VS Code extensions (.oauth-tokens/vscode_mcp.json) - Claude Code/Roocode (.oauth-tokens/mcp.json) - Custom MCP clients (standard configuration format)

Troubleshooting¶

Common Issues¶

Cannot authenticate with Cognito - Verify credentials in .env - Check user pool ID format - Ensure client has proper Cognito configuration

External provider authentication fails - Verify redirect URI matches provider configuration - Check client ID/secret are correct - Ensure required scopes are configured

Permission denied for specific tools - Check your Cognito group memberships - Verify scope mappings in scopes.yml - Ensure tool names match exactly

Testing and Validation¶

MCP Gateway Testing Tools¶

Use the comprehensive testing script to validate your authentication setup:

# Test basic connectivity
./tests/mcp_cmds.sh basic

# Test MCP connectivity with authentication
./tests/mcp_cmds.sh ping

# List available tools (filtered by your permissions)
./tests/mcp_cmds.sh list

# Call specific tools
./tests/mcp_cmds.sh call debug_auth_context '{}'
./tests/mcp_cmds.sh call intelligent_tool_finder '{"natural_language_query": "quantum"}'

# Test against different gateway URLs
GATEWAY_URL=https://your-domain.com/mcp ./tests/mcp_cmds.sh ping
./tests/mcp_cmds.sh --url https://your-domain.com/mcp list

The testing script automatically: - Detects localhost vs external URLs - Loads appropriate authentication credentials from .oauth-tokens/ingress.json - Handles MCP session establishment and authentication headers - Provides clear error messages for debugging

Credential Validation¶

# Validate all OAuth configurations
cd credentials-provider
./generate_creds.sh --verbose

# Test specific authentication flows
./generate_creds.sh --ingress-only --verbose    # Test MCP Gateway auth
./generate_creds.sh --egress-only --verbose     # Test external provider auth
./generate_creds.sh --agentcore-only --verbose  # Test AgentCore auth

Authentication Flow Testing¶

1. Ingress Authentication (MCP Gateway access):

   python credentials-provider/oauth/ingress_oauth.py --verbose


2. Egress Authentication (External services):

   python credentials-provider/oauth/egress_oauth.py --provider atlassian --verbose


3. AgentCore Token Generation:

   python credentials-provider/agentcore-auth/generate_access_token.py --debug


Setting Up Groups in Keycloak¶

This section provides step-by-step instructions for entry-level platform engineers to set up and manage groups in Keycloak for the MCP Gateway.

Prerequisites Checklist¶

Before starting group setup: - ✅ Keycloak is running (check: docker-compose ps keycloak) - ✅ You have admin credentials (default: admin / your-configured-password) - ✅ You can access the admin console at https://your-domain/admin or http://localhost:8080/admin - ✅ The mcp-gateway realm exists (created by init-keycloak.sh)

Understanding Groups in Keycloak¶

What are Groups?¶

Groups in Keycloak are collections of users that share common permissions. Think of them as departments in a company - all members inherit the same access rights.

Why Use Groups for MCP Gateway?¶

• Simplified Management: Assign permissions once to a group, not individually to each agent
• Scalability: Easy to add new agents with same permissions
• Audit Trail: Track which agents belong to which permission sets
• Security: Principle of least privilege - agents only get necessary access

MCP Gateway Group Structure¶

mcp-gateway (realm)
├── mcp-servers-unrestricted (group)
│   └── Full access to all MCP servers and tools
└── mcp-servers-restricted (group)
    └── Limited access to specific MCP servers and tools

Step-by-Step: Creating Groups via Keycloak Admin Console¶

Step 1: Access the Admin Console¶

1. Open your browser and navigate to:
2. Local: http://localhost:8080/admin

3. Production: https://mcpgateway.ddns.net/admin

4. Login with admin credentials:

   Username: admin
   Password: <your-admin-password>


Note: If you don't know the password, check with your team lead or the person who set up Keycloak.

Step 2: Navigate to the Correct Realm¶

1. Check current realm - Look at the top-left dropdown
2. Switch to mcp-gateway realm if not already selected:
3. Click the realm dropdown
4. Select mcp-gateway

Important: Always ensure you're in the mcp-gateway realm, not the master realm!

Step 3: Create the Required Groups¶

1. Navigate to Groups:
2. In the left sidebar, click Groups

3. You'll see either existing groups or an empty list

4. Create the first group (mcp-servers-unrestricted):

5. Click the Create group button
6. Enter exactly: mcp-servers-unrestricted
7. Leave Parent as "none"

8. Click Create

9. Create the second group (mcp-servers-restricted):

10. Click Create group again
11. Enter exactly: mcp-servers-restricted
12. Leave Parent as "none"
13. Click Create

Critical: The group names must match EXACTLY (case-sensitive) for the auth server to recognize them!

Step 4: Verify Group Creation¶

1. Check the groups list:
2. Both groups should appear in the Groups list

3. They should be at the root level (no parent)

4. Verify group paths:

5. Click on each group
6. Check the path shows: /mcp-servers-unrestricted or /mcp-servers-restricted

Assigning Service Accounts to Groups¶

Service accounts (used by AI agents) need to be added to groups to get permissions.

Method 1: Via User Management (Recommended for Individual Agents)¶

1. Navigate to Users:
2. Click Users in the left sidebar

3. Search for the service account (e.g., agent-sre-agent-m2m)

4. Add to Group:

5. Click on the service account name
6. Go to the Groups tab
7. Click Join Group
8. Select either:
   • mcp-servers-unrestricted for full access
   • mcp-servers-restricted for limited access

9. Click Join

10. Verify Membership:

11. The group should now appear in the user's group list
12. Shows the group path and when they joined

Method 2: Via Group Management (Good for Bulk Operations)¶

1. Navigate to Groups:
2. Click Groups in the left sidebar

3. Click on the target group

4. Add Members:

5. Go to the Members tab
6. Click Add member
7. Search for service accounts (type "agent" to see all)
8. Select the accounts you want to add
9. Click Add

Group Configuration for Different Agent Types¶

Decision Tree for Group Assignment¶

Is this agent for...
│
├── Production/Critical Operations?
│   ├── Yes → mcp-servers-unrestricted
│   │   Examples: SRE agents, monitoring agents
│   │
│   └── No → Continue ↓
│
├── Customer-Facing or Limited Scope?
│   ├── Yes → mcp-servers-restricted
│   │   Examples: Travel assistants, chatbots
│   │
│   └── No → mcp-servers-restricted (default to restricted)
│
└── Development/Testing?
    └── Create a custom group or use mcp-servers-restricted

Validating Your Group Setup¶

Quick Validation Checklist¶

1. Groups exist in Keycloak ✓

   # Check via admin console: Groups section should show both groups


2. Service accounts have group membership ✓

   # Check via admin console: Users → [service-account] → Groups tab


3. Test token generation with groups ✓

   # Generate a token for an agent
   cd credentials-provider
   python token_refresher.py --agent-id <agent-name>

   # Check the token contains groups
   cat .oauth-tokens/agent-<agent-name>.json | jq '.access_token' | \
     cut -d. -f2 | base64 -d | jq '.groups'

   # Should show: ["mcp-servers-unrestricted"] or ["mcp-servers-restricted"]


4. Verify auth server recognizes groups ✓

   # Test authentication with the token
   ./test-keycloak-mcp.sh --agent-id <agent-name>

   # Check auth server logs for group mapping
   docker-compose logs auth-server | grep -i "groups.*mapped"
   # Should see: "Mapped Keycloak groups ['mcp-servers-unrestricted'] to scopes..."


Troubleshooting Group Issues¶

Issue: "Access forbidden" even though user is in group¶

Symptoms: - Agent gets 403 Forbidden errors - Logs show "Access denied" messages

Solutions: 1. Verify exact group names:

# Groups must be named EXACTLY:
# ✓ mcp-servers-unrestricted
# ✗ mcp-servers-Unrestricted (wrong case)
# ✗ mcp_servers_unrestricted (underscores instead of hyphens)

1. Check group mapper configuration:
2. Go to Clients → mcp-gateway-m2m → Client scopes

3. Check that "groups" mapper exists and is enabled

4. Regenerate token after group changes:

   python credentials-provider/token_refresher.py --agent-id <agent-name> --force


Issue: Groups not appearing in JWT token¶

Symptoms: - Token doesn't contain groups claim - Auth server can't map groups to scopes

Solutions: 1. Ensure groups mapper is configured: - Navigate to: Clients → mcp-gateway-m2m → Client scopes → Mappers - Should have a "groups" mapper - If missing, run: ./keycloak/setup/init-keycloak.sh

1. Check service account has "view-groups" role:
2. Users → [service-account] → Role mappings
3. Should have "view-groups" client role

Issue: Can't create groups - "Forbidden" error¶

Symptoms: - Admin console shows permission errors - Can't create or modify groups

Solutions: 1. Verify you're logged in as admin: - Logout and login with the admin account - Not a regular user account

1. Check you're in the correct realm:
2. Must be in mcp-gateway realm to create groups there
3. Master realm admin can switch to any realm

Best Practices for Group Management¶

1. Naming Conventions:
2. Use the exact names: mcp-servers-unrestricted and mcp-servers-restricted

3. Don't create variations or abbreviations

4. Documentation:

5. Keep a record of which agents are in which groups

6. Document why an agent needs unrestricted access

7. Regular Audits:

8. Monthly: Review group memberships
9. Quarterly: Audit unrestricted access needs

10. Remove agents that no longer need access

11. Testing After Changes:

12. Always regenerate tokens after group changes
13. Test agent access to verify permissions work

Additional Resources¶

• Complete Configuration Reference
• Amazon Cognito Setup Guide
• Complete Fine-Grained Access Control Documentation
• OAuth Provider Configurations
• MCP Testing Tools
• Source: Auth Server Implementation
